SimMan 3G

• Completely wireless and self-contained
• Internal electrical and pneumatic power
• Supplemental wired connectivity and power
• Wirelessly integrates with existing computer networks
• Swappable, rechargeable batteries
• Approximately 4 hours continuous operation in wireless mode
• Rugged and reliable for use in multiple environments

Multiple Airway Skills/Features:

• Controllable open/closed airway; automatically or manually controlled
• Head tilt/Chin lift
• Jaw thrust w/articulated jaw
• Suctioning (Oral & Nasopharyngeal)
• Bag-mask ventilation
• Orotracheal intubation
• Nasotracheal intubation
• Combitube, LMA, and other airway placement
• Endotracheal tube intubation
• Retrograde intubation
• Fiberoptic intubation
• Transtracheal jet ventilation
• Needle cricothyrotomy
• Surgical cricothyrotomy
• Variable lung compliance
  • 4 settings
• Variable airway resistance
  • 4 settings
• Right main stem intubation
• Stomach distention

Airway Complications:

• Detection of proper head position
• Can’t intubate/Can ventilate
• Can’t intubate/Can’t ventilate
• Tongue edema
• Pharyngeal swelling
• Laryngospasm
• Decreased cervical range of motion
• Trismus

Breathing Features:

• Simulated spontaneous breathing
• Bilateral and unilateral chest rise and fall
• CO2 exhalation
• Normal and abnormal breath sounds
  • 5 anterior auscultation sites
  • 6 posterior auscultation sites
• Oxygen saturation and waveform

Breathing Complications:

• Cyanosis
• Needle thoracentesis - bi-lateral
• Unilateral & Bilateral chest movement
• Unilateral, Bilateral & lobar breath sounds
• Chest tube insertion - bilateral

Cardiac Features:

• Extensive ECG library
• Heart sounds - four anterior locations
• ECG rhythm monitoring (4 wire)
• 12 lead ECG display
• Defibrillation and cardioversion
• Pacing

Circulation Features:

• Manual BP measurement
• Carotid, femoral, brachial, radial, dorsalis pedis, popliteal and posterior tibialis pulses synchronized with ECG
• Pulse strength variable with BP
• Pulse Palpation is detected & logged

Vascular Access:

• IV access
• Intraosseous access (tibia)
• IM acces, dorsogluteal

CPR:

• Compliant with 2020 Guidelines
• CPR compressions generate palpable pulses, blood pressure wave form, and ECG artefacts
• Realistic compression depth and resistance
• Detection of depth, release and frequency of compressions
• Real time feedback on quality of CPR

Eyes:

• Blinking - slow, normal, fast and winks
• Open, closed and partially open
• Pupillary accommodation:
  • synchrony/asynchrony
  • normal and sluggish speed of response

Other Features:

• Seizure/Fascicullation
• Bleeding
  • Simulation of bleeding at multiple sites
  • Arterial and venous
  • Vital signs automatically respond to blood loss & therapy
  • Works with various wound modules & moulage kits
• Urine output (variable)
• Foley catheterization
• Secretions
  • Eyes, Ears, Nose, Mouth
  • Blood, Mucous, CSF, etc.
• Diaphoresis
• Bowel Sounds - four quadrants
• Patient Voice
  • Pre-recorded sounds
  • Custom sounds
  • Instructor can simulate patient’s voice wirelessly
• Instructor Communication
  • Multiple instructors communicate using integrated voice over IP
• Simulated SpO2 measurement

Pharmacology:

• Extensive drug formulary
• Automatic or programmable physiological responses

System Features:

• Control multiple manikins from one interface
• Control simulations from any where on your network
• Multiple interfaces can control/observe a single simulation
• Manual Mode
  • Precise control “on the fly”
  • Design & program custom scenarios
  • Create custom events
  • Run pre-packaged scenarios
• Automatic Mode
  • Physiological & pharmacological models run pre-packaged simulations
  • Unique, simple controls increase/decrease difficulty & pace
• Simulation controls:
  • Fast forward
  • Pause
  • Rewind
  • Save/Restore
  • Profile Editor
  • Future prediction & patient outcome display
  • Integrated video debriefing
  • Data logging
  • Instructor comments

Patient Monitor:

• Wireless
• Highly configurable
• Includes:
  • ECG (2 traces)
  • SpO2
  • CO2
  • ABP
  • CVP
  • ICP
  • Anesthetic Agent
  • PH
  • PTC
  • PAP
  • PCWP
  • NIBP
  • TOF
  • Cardiac Output
  • Temperature (core & peripheral)
  • Additional and programmable parameters
• X-Ray Display
• 12 Lead ECG Display
• Custom Image Display
• Custom Video Display
