Completely wireless and self-contained
- Internal electrical and pneumatic power
- Supplemental wired connectivity and power
- Wirelessly integrates with existing computer networks
- Possibility to attach an additional battery on the side to extend the use
- Rugged and reliable for use in multiple environments
Multiple Airway Skills/Features:
- Controllable open/closed airway; automatically or manually controlled
- Head tilt/Chin lift
- Jaw thrust w/articulated jaw
- Suctioning (Oral & Nasopharyngeal)
- Bag-mask ventilation
- Orotracheal intubation
- Nasotracheal intubation
- Combitube, LMA, I-gel and other airway placement
- Endotracheal tube intubation
- Retrograde intubation
- Fiberoptic intubation
- Transtracheal jet ventilation
- Needle cricothyrotomy
- Surgical cricothyrotomy
- Airway resistance - 3 settings (On/Off/Half)
- Right main stem intubation
- Stomach distention
Airway Complications:
- Tongue fallback
- Tongue edema
Breathing Features:
- Simulated spontaneous breathing
- Bilateral and unilateral chest rise and fall
- Normal and abnormal breath sounds
- Lung auscultation sites: posterior and anterior sites
- Oxygen saturation and waveform
Breathing Complications:
- Cyanosis
- Needle thoracentesis – bi-lateral
- Unilateral & Bilateral chest movement
- Chest tube insertion – bilateral
Cardiac Features:
- Extensive ECG library
- Heart sounds
- ECG rhythm monitoring (4 wire)
- 12 lead ECG display
- Defibrillation and cardioversion with live shock – Laerdal LINK technology
- Pacing
Circulation Features:
- BP measured manually by auscultation of Korotkoff sounds
- Carotid, femoral, radial pulses synchronized with ECG
- Pulse strength variable with BP
- Pulse Palpation is detected & logged
Vascular Access:
- IV access (right arm)
- Intraosseous access (tibia)
CPR:
- Compliant with 2010-2015 Guidelines
- CPR compressions generate palpable pulses, blood pressure wave form, and ECG artefacts
- Realistic compression depth and resistance
- Detection of depth, release and frequency of compressions
Eyes:
- Manually set to: Open, closed and partially open
- Set of interchangeable pupils
Other Features:
- Foley catheterization without urine output
- Pre-prepared for use of the SonoSim Ultrasound solution
- Patient Voice
- Pre-recorded sounds
- Custom sounds
- Instructor can simulate patient’s voice wirelessly
System Features:
- Wireless tablet PC controls simulator remotely or SimPad Plus system
- Control simulations from anywhere on your network
- Manual Mode
- Precise control “on the fly”
- Automatic Mode
- Run pre-packaged scenarios
- Unique, simple controls increase/decrease difficulty & pace
- Integrated video debriefing
- Data logging
- Instructor comments
- Scenarios available on Laerdal Scenario Cloud
Patient Monitor:
- Wireless
- Highly configurable
- Includes (depending on the operating system):
- ECG (2 traces)
- SpO2
- CO2
- ABP
- CVP
- ICP
- Anesthetic Agent
- PH
- PTC
- PAP
- PCWP
- NIBP
- TOF
- Cardiac Output>
- Temperature (core & peripheral)
- Additional and programmable
Parameters:
LLEAP
- X-Ray Display
- Custom Image Display
- Custom Video Display
Accessories:
- Operating system:
- LLEAP PC or SimPad Plus®
- Simulated Patient Monitor & Software
- Scenarios are available on Laerdal Scenario Cloud
